CellarPro Air Handler AH4500SCv-ECX Vertical #36296
CellarPro Air Handler AH4500SCv-ECX Vertical #36296
No se pudo cargar la disponibilidad de retiro
Brand: CellarPro
Size: 18 3/5w x 18 3/5d x 37 9/10h (in), 8-inch ducting
Weight: 212 lbs
Power/Rating:
- CellarPro Air Handlers use two 110V / 60Hz plug-in power cords, as follows:
- Running Amps Cord-Connected: 10.6 Amps
- Total Watts: 636 (medium fan speed)
- 1/2 Ton Nominal
BTUH @ 55F
- Low Fan Speed: 3607
- Med Fan Speed: 3975
- High Fan Speed: 4328
Decibels
Evaporator Decibels
- Low Fan Speed, Ducted: 38 dbA
- Med Fan Speed, Ducted: 44 dbA
- High Fan Speed, Ducted: 52 dbA
Condenser Decibels
- Low Fan Speed, Ducted / Non-Ducted: 43 dbA / 56 dbA
- Med Fan Speed, Ducted / Non-Ducted: 50 dbA / 63 dbA
- High Fan Speed, Ducted / Non-Ducted: 55 dbA / 68 dbA
Sizing Table: Click here to view sizing table
Size: 18 3/5w x 18 3/5d x 37 9/10h (in), 8-inch ducting
Weight: 212 lbs
Power/Rating:
- CellarPro Air Handlers use two 110V / 60Hz plug-in power cords, as follows:
- One cord for the compressor, which pulls 7.4 amps and requires a dedicated 15 amp circuit breaker
- One cord for the rest of the components, which pull 3.2 amps and require a dedicated 15 amp circuit breaker
- Running Amps Cord-Connected: 10.6 Amps
- Total Watts: 636 (medium fan speed)
- 1/2 Ton Nominal
BTUH @ 55F
- Low Fan Speed: 3607
- Med Fan Speed: 3975
- High Fan Speed: 4328
Decibels
Evaporator Decibels
- Low Fan Speed, Ducted: 38 dbA
- Med Fan Speed, Ducted: 44 dbA
- High Fan Speed, Ducted: 52 dbA
Condenser Decibels
- Low Fan Speed, Ducted / Non-Ducted: 43 dbA / 56 dbA
- Med Fan Speed, Ducted / Non-Ducted: 50 dbA / 63 dbA
- High Fan Speed, Ducted / Non-Ducted: 55 dbA / 68 dbA
Sizing Table: Click here to view sizing table
